Panel Assist WebNew Value For Control Panels

Select Products

Optimal items will be found by model numebers and spec search of each product category.

Applicable items for control panels will be suggested automatically.

If applicable products are not suggested, please "Add an item by entering product information" of each BOM list. LOGINBOM Management

Panel Solutions

We are offering practices and solutions to miscellaneous problems for control panels.

BOM Management

By creating BOMs, contents download, replacement exploration and panel design support tool usage are available for registered products.

Open the existing list

BOMs will be creted by choosing products from the "Select Items" and importing a designated Excel format file.

Please take a look at the operation guide for the "BOM" -- the main feature of the "Panel Assist Web".

Design Support Tool/Contents

Thermal related risks can be foreseeable by adding simple panel information to selected products. So, backtracking processes in panel design can be avoidable in advance.

Electric specifications and applicable wires for selected products will be displayed automatically. So, terminal blocks can be chosen easily, which are required for wiring components.

E3.series (ZUKEN) and *ECAD Library (EPLAN) downloads are available. *Electric CAD data with power related specs required for electrical design

Status of certification and conformity to its destination's local standards is confirmable by model number. Certifications and conformity declarations are also downloadable.

Common product summary, features, operating principles and technical terms are checkable for each product category.

Please read the cautions that are in common among each category.
